SP4824 Series Ultra-Compact GPS Tracking Device

SP4603 Series Feature-Rich GPS Tracking Device

The SP4824 is our latest generation GPS tracking device, optimized to meet all carrier and country certifications. The SP4824 is designed to withstand the harshest of conditions associated with vehicle telematics. This latest generation device can be widely used across all vehicle location applications ranging from subprime automotive needs to fleets, to consumer telematics. The SP4824 has multiple input/output interfaces that can be used for monitoring or controlling external devices. The SP4824 features the latest in cellular antenna designs with optimization and improved logic to reach and operation in the most challenging urban and rural environments. The SP4824 is equipped with the latest firmware design with optimized over-the-air capability. Users can also use the SP4824 to monitor the status of a vehicle and the control the vehicle by its external relay output.

Download the brochure

Features

  • LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66/CAT1

  • LTE-TDD: B40

  • WCDMA: B1/B2/B4/B5/B8

  • Integrated cellular and GPS antennas
  • GSM/EDGE: B2/B3/B5/B8I

  • Integrated high-precision GPS engine
  • Support UDP and TCP for data communications
  • 1 Ignition Input
  • Excellent GPS tracking and acquisition sensitivity
  • 3 Digital Outputs
  • Micro-sized device allowing easier and more covert installations
  • Cost effective solution for GPS tracking

SP4824 Series Specifications

Cellular
GSM/EDGE: B2/B3/B5/B8I
WCDMA: B1/B2/B4/B5/B8
Operating Bands: LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28/B66/CAT1
LTE-TDD: B40
GPS

Receiver: UBLOX 7020

Sensitivity: Hot Start: <3s, Cold Start < 35s
Accuracy: Autonomous: -162dB <5 m
GPS Frequency: L1, 1575.42 MHz
GPS Channels: 22

Connectors

Audio: Two way (Optional)
Cell Antenna: Integrated
GPS Antenna: Integrated
Connector Type: 19 Pins Integrated
1-Wire

Input/Output

Digital Input: One positive trigger for ignition detection, 3 negative digital Inputs
Digital Outputs: 3 digital outputs
1 Analog input (12V)
Communication Port: RS232 (RX/TX)

Air Interface

Scheduled Timing Report: Report position and status at preset intervals
Geo-Fence: Geo-fence alarm, support up to 5 circular or polygon geo-fence regions
Power On Report: Report when the device is powered on
Data Support: UDP and TCP

Environmental

Operating Temperature: -30C ~ +80C
Storage Temperature: -40℃ ∼ +85℃

Physical

Dimensions: 87mm x 55mm x 12.5mm
Weight: 80g

Electrical

Operating Voltage: DC 8V to 32V
Backup Battery: Li-Polymer 180 mAh – 3.7V

Compliance

FCC Compliance: IP67

Mounting

Tie Wrap, Velcro, or Adhesive
